Battery Stacker-1091

Battery Stacker-1091

We are engaged in manufacturing of the Battery Stacker, exporters, Battery Stacker wholesalers, Battery Stacker traders, Battery Stacker producers, Battery Stacker suppliers, Battery Stacker manufacturers, Battery Stacker manufacturer, Battery Stacker manufacturing companies, Battery Stacker companies for your sourcing needs, Battery Stacker Manufacturers, Battery Stacker Suppliers & Exporters, Battery Stacker production centers.


  • Fork length: 1150mm/as per customer requirement
  • Fork width: 600mm/as per customer requirement
  • Fork: 150mm
  • Lower height: 90mm/100mm
  • Raised height:
    1600mm/1800mm/2000mm/2500mm/3000mm/as per customer requirement
  • Mast system : single/double/triple mast system
  • Lower speed: continuously variable
  • Pump : simple and reliable hydraulic system
  • Wheels : dust free nylon wheels with double sealed bearings.
  • Wheels steering and support wheels : 2 nylon wheels ø 180 x 50mm
  • Load wheels : 4 nylon wheels ø 80 x 70mm
  • Color: golden yellow powder coated color
  • Handle : drawbar with finger protection clamp and release handle
  • Structure : simplex single mast structure made from heavy duty ‘c’ channel section. It would be supported by heavy-duty deep grooved guide rollers. Forks lifting would be by means of 2 nos. Duplex chain & design pulley.
  • Hydraulic unit : hydraulic cylinder part would be supported by single acting cylinder piston rod is inducted with hard chrome plated. The sealing arrangement is of polyurethane seals, teflon seals for long life smooth working. Leak proof viper seals will be given to protect from ingress dirt & dust.PATEL
  • DC power pack unit (optional)
  • DC Power Pack-1nos
  • 12 Volts/24volts Dc Motor-1nos
  • 12 liter Ms/platic Oil Tank-1nos
  • 1.5kw/2.0kw, 2.2cc/rev Gear Pump With Single Acting Valve Block-1nos
  • 12volts/24volts 150 Ampier Exide/tata/standard Make Battery-1nos
  • 12volts/24volts 15 A Smps Based Battery Charger (230volts Ac To 12v/24v Dc)-1nos
  • Up Position By Push Control System-1nos
  • Down Position By Push Control System-1nos
  • Key Lock System Operated Battery Stacker To Control Miss Use Of Equipment-1nos
  • Pressure relief valve - 1nos
  • Many fold block - 1nos
  • Suction filters - 1nos
  • D. C electric solenoid valve - 1nos
  • Pilot operated check valve - 1nos
  • Phase a. C motor - 1nos
  • Flow control valve - 1nos
  • Completed fitting accessory - 1nos
Patel offers
  • Hard chromed, polished pistons that are resistant to rust,
  • Scratches and wear
  • Double sealed high pressure polyurethane packing
  • To ensure long life of the hydraulic system
  • To prevent leakages
  • Ergonomically designed steering handle
  • For easy operation from all angles
  • To reduce pulling power and minimize operation fatigue
  • Light and compact construction
  • Mast:made of quality steel bent in c profiles. Inner and outer mast furnished with thrust rollers to prevent lateral play.
  • Carriage:the carriage has an open centre section and low profiled forks with inner reinforcement.

Additional Information

  • Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer),D/P,D/A,Other
  • Port of Dispatch: Mumbai, INDIA
  • Production Capacity: 30000 PER MONTH
  • Delivery Time: READY STOCK
  • Packaging Details: EXPORT QUALITY STANDARD
